| MODEL |
|
K-3 |
K-3-T |
K-3-2 |
K-3-2-T |
| Steel brg + greased |
min-1 |
18,000 |
|
18,000 |
18,000 |
| Ceramic brg + greased |
min-1 |
24,000 |
24,000 |
24,000 |
24,000 |
| Ceramic brg + Oil-Air Lubrication |
min-1 |
33,000 |
|
33,000 |
|
| Power |
Kw |
3.2 |
3.2 |
5.5(7) |
5.5(7) |
| Voltage |
V |
220, 380 |
220, 380 |
220, 380 |
220, 380 |
| Pole |
P |
4 |
4 |
4 |
4 |
| Tooling System |
|
BT30, HSK32E |
BT30, HSK32E |
BT30, HSK40E |
BT30, HSK40E |
| Weight |
Kg |
18 |
18 |
20 |
20 |
| Tool change pressure |
Kg/Р |
5 |
5 |
5 |
5 |
| Torque |
Nm |
|
|
|
|
| Tool release |
|
Air |
HY(Booster) |
Air |
HY(Booster) |
| Encoder |
Pulse |
|
|
|
|
| Internal Coolant Supply |
|
|
TSC Type |
|
ESC Type |
| Application |
|
Engraving
Mook-up
Back light |
Engraving
Mook-up
Back light |
Engraving
Mook-up
Back light |
Engraving
Mook-up
Back light |
|
